Condensing Unit

Product name: Condensing Unit Rack Characteristics: Compressor type:Full/semi-hermetic scroll comp.and semi-hermetic reciprocating comp. Refrigerant: R22/R404A/R410A Rack type: standard/high efficient scroll unit(hanging type), air/water cooling reciprocating unit, box type reciprocating unit…

Product name: Condensing Unit
Rack Characteristics:
Compressor type:Full/semi-hermetic scroll comp.and semi-hermetic reciprocating comp.
Refrigerant: R22/R404A/R410A
Rack type: standard/high efficient scroll unit(hanging type), air/water cooling reciprocating unit, box type reciprocating unit, box type reciprocating unit
Scroll unit looks like air-conditioning outside unit, easy installation and rain protection free
Air/water cooling reciprocating unit configuration reasonably and running stability, with simple structure convenient for operation and maintenance.
Box type recip.unit with semi-hermetic comp. and V type condenser for outdoor installation.

Standard conf
3igurations
scroll condensing unit
High strength sheet-metal package design
Painting RAL9010
With high/low pressure gauge and high/low pressure switch
Compressor with lubricant oil before delivery
Compressor overheating and overcurrent protection
Compressor crankcase heater
Liquid line filter inlet and outlet shutoff valves
Filter inlet and outlet shutoff valves
Rack with axial flow fan and high efficient copper-aluminum fin condenser
LT unit with liquid injecting or vapor injecting


Air-Water Cooling Reciprocating unit
High-strength sheet-metal frame design.
Painting RAL5010
With high/low pressure gauge and high/low pressure switch
Compressor with lubricant oil before delivery
Compressor high temp.discharging protection
Compressor suction and discharge shutoff valves
Compressor crankcase heater
Reciprocating Comp.with oil pressure switch
Compressor cooling injection for LT R22
Cylinder head cooling fan for LT Single-stage
Liquid line filter inlet and outlet shutoff valves
Rack with axial flow fan and high efficient copper-aluminum fin condenser or high efficiency shell-tube condenser
Rack with oil separator
Dual stage LT unit with subcooler
LT unit with accumulator

Box Type unit
High-strength sheet-metal  package design.
Painting RAL9010
With high/low pressure gauge and high/low pressure switch
Compressor with lubricant oil before delivery
Compressor high temp.discharging protection
Compressor suction and discharge shutoff valves
Compressor crankcase heater
Reciprocating Comp.with oil pressure switch
Compressor cooling injection for LT R22
Cylinder head cooling fan for LT Single-stage
Liquid line filter inlet and outlet shutoff valves
Compressor suction and discharge shutoff valves
Compressor crankcase heater
Reciprocating Comp.with oil pressure switch
Compressor cooling injection for LT R22
Cylinder head cooling fan for LT Single-stage
Liquid receiver inlet and outlet shutoff valves
Liquid line filter inlet and outlet shutoff valves
Rack with external rotator axial flow fan and high efficient copper-aluminum fin condenser efficiency shell-tube condenser
Rack with oil separator
Dual stage LT unit with subcooler
LT unit with accumulator

Electrical Control
Circuit breaker, contactor, thermal overload per compressor
On/Off switch per compressor
discharge temperature protection per compressor
High/low pressure protection per compressor
Power/Running/Alarm light per compressor
Oil pressure protection per compressor
Direct or part winding start of the compressor
Lack/fault phase and over/under-voltage protection
Power supply and control of condenser

Options Compressor Rack
Compressor with oil level regulator
Backup suction filter elements
Backup liquid filter elements
Oil strainer and oil sight glass
Sight glass and filter drier with replaceable core
3/8“ SAE refrigerant charging valve
Liquid receiver low level liquid filter
Dual safety relief valve convenient for maintenance and annual inspection, 28Bar for R404A, 24Bar for R22

Options Electrical Control
Rack main circuit breaker
Total suction/discharge pressure protection & Alarm
Compressor part winding start
Low level liquid Alarm
condenser mechanical pressure control
Ammeter & Voltmeter
Emergency stop button

Non-standard Customization Racks
Scroll condensing unit dual compressor design, and one digital compressor optional for energy saving
Rack with water cooled plate-type condenser
