Polyurethane Sandwich Panel

Heat Insulation Polyurethane Panel

Category:

Polyurethane Sandwich Panel

Heat insulation pu sandwich panel is suitable for the projects which have strict requirement,Polyurethane core material is considered to the best material in keeping warm and thermal insulation.

The Polyurethane block material become steady,then combining with metal plates. The characteristics of this technique are: the polyurethane foam, after this chemical reaction is stable, we cut the polyurethane into pieces which with different thickness. The polyurethane sheet material has stable physical performance, it can combine with pre-painted hot galvanized steel sheets or stainless steel sheet, the surface is smooth and the whole performance is excellent.





Specification

Steel Thickness0.376~0.8mm
Panel thickness50/75/100/125/150 /180/200mm
Effective width

(1) 960/mm —for roof

(2) 925/960/1125mm—for wall or ceiling

LengthAccording to customer’s request,less than 11.8m
MaterialsInner is PU, two sides is Color steel tile
Structure

three layers:

(1)upper layer is steel sheet,

(2)the inner layer is PU sandwich,

(3)the bottom layer is also steel sheet

Density38-45(kg/m³),etc
colorblue,white grey or other colors .
Parts

Steel line for easy connect one by one

Film covering in order to protect the steel of panels

Lifetime15-20 years
CharacterLight in weight, heat insulation, fireproof and waterproof,environmental
Usage

various roofs and walls referring to the large size factory buildings,storages,

exhibition halls, gymnasiums ,etc

PackingPacked by shipping Container or according to your demands
